The retractable arm system of this xcmg mobile crane 25 ton for sale has great flexibility and can adjust the arm length according to actual needs to adapt to different working environments and lifting height requirements. The 25-ton lifting capacity enables it to efficiently lift heavy equipment, materials and components, and is widely used in construction engineering, mining, equipment installation and other fields.
This xcmg mobile crane 25 ton for sale has become the preferred reliable working tool in many industries through its powerful structural design, intelligent control, safety assurance system, and efficient power system, which can meet the lifting needs under different working conditions.
This xcmg mobile crane 25 ton for sale adopts an efficient power system and optimized hydraulic technology, making the working performance of the whole machine more outstanding. Its power system can provide stable and powerful power output in various working environments through efficient engines and advanced power transmission technology. Whether under high load, long-term operation or complex working conditions, the power system can ensure that the crane can continuously and stably complete the lifting task, while reducing fuel consumption and energy waste.
Xcmg QY25K5-I 48m Mobile Crane 25 ton Price
Xcmg QY25K5-I 48m Mobile Crane 25 ton Price
Xcmg QY25K5-I 48m Mobile Crane 25 ton Price
Xcmg QY25K5-I 48m Mobile Crane 25 ton Price
Xcmg QY25K5-I 48m Mobile Crane 25 ton Price
Overall length: 12300mm
Overall width: 2500mm
Overall Height: 3350mm
Wheel Base: 4425+1350mm
Track: 2074/1834/1834mm
Total vehicle mass in travel configuration: 31750kg
Front axle: 6550kg
Rear axle: 25200
Engine Model: SC8DK280Q3
Engine rated power: 206/2200kw/(r/min)
Engine rated torque: 1112/1400N.m/(r/min)
Max. travel speed: 80km/h
Min. turning diameter: 22m
Min. ground clearance: 275mm
Max. grade ability: 40%
Approach angle: 16°
Departure angle: 13°
Braking distance (at 30 km/h, full load ): ≤10m
Oil consumption per 100km: ≤37L
Exterior noise level during acceleration traveling: 88dB (A)
Noise level at seated position: 90dB (A)
1. This xcmg 25 ton crane price uses a main arm made of high-strength steel. The selection of this material ensures that the crane can maintain structural stability and durability when bearing large loads. The main arm design has been precisely calculated and optimized, using advanced structural analysis technology, taking into account the stress distribution under different loads and working conditions, thereby greatly improving its ability to resist bending, tension and compression. In extreme working environments, such as high temperature, low temperature or severe wind conditions, the main arm can still maintain excellent load-bearing capacity to ensure safety and stability during operation. In addition, the refined main arm design also effectively reduces the weight of the crane and improves its overall performance and load capacity. With the increase in the use cycle, the corrosion resistance and fatigue resistance brought by the use of high-strength steel further extend the service life of the crane and reduce maintenance and replacement costs.
2. This xcmg 25 ton crane price is equipped with an advanced hydraulic system, which consists of multiple high-efficiency hydraulic components. Through fine adjustment and coordination, it ensures the efficiency and stability of the crane when performing various lifting tasks. The hydraulic system can provide strong power support, so that lifting, telescoping and slewing can be completed quickly and smoothly, which significantly improves work efficiency. Especially during operation, the hydraulic system can automatically adjust the pressure and flow to ensure that the crane can operate smoothly under different loads, avoiding mechanical damage caused by excessive load or uneven pressure. The high efficiency of the hydraulic system not only enhances the operating capacity of the equipment, but also reduces fuel consumption, reduces energy waste, and maintains excellent operating conditions during long-term continuous work.
3. The walking system of this xcmg 25 ton crane price adopts high-quality drive devices and hydraulic supports, so that the crane can maintain high passability and stability on uneven ground. The four-wheel drive system can ensure that it can move quickly and smoothly in complex terrain, greatly improving work efficiency and convenience of operation.
4. This xcmg 25 ton crane price is equipped with an advanced intelligent control system that can monitor the working status of the equipment in real time and provide accurate operation information. The control interface is simple and easy to understand, which can help operators grasp key information such as lifting parameters, operation time, load conditions, etc. in real time. This intelligent system not only improves the accuracy of the operation, but also effectively avoids operating errors and ensures the safety of the operation.
5. This xcmg 25 ton crane price is equipped with a variety of safety devices, such as anti-overload protection, automatic level detection, emergency stop system, etc., to ensure the safety of the equipment during use. In addition, the overall design of the crane takes into account the stability during operation. The wide outriggers and stable chassis structure can maintain good stability in different working environments to prevent rollover or instability.
